Metal-free restorations: 2006 all-ceramic update

All-ceramic restorations continue to make inroads into the overall restorative market at the rate of about 1 to 2 percent each year.

Th 0611demet01

All-ceramic restorations continue to make inroads into the overall restorative market at the rate of about 1 to 2 percent each year. In 2000, approximately 20 percent of restorations were all-ceramic, and year to date in 2006 it has risen to 31 percent of restorations. Metal-free restorative options include composites, pressed ceramics, and cementable all-ceramic products. Each of these metal-free options has a place in current esthetic restorative dentistry, and I will share what I think are the proper indications for each of these materials. Certainly, we have seen failures in the lab when dentists attempt to push these materials beyond their indications. There are still several clinical situations that call exclusively for the use of PFM restorations, but that list of situations is shrinking.

Th 0611demet01
Fig. 1 - Clinical case one. This 37-year-old male had multiple failing composites, recurrent decay, and broken incisal edges due to parafunctional activity. For these reasons, zirconia crowns were a better choice than porcelain veneers.
Click here to enlarge image

One interesting trend in the all-ceramic segment is how the indirect composite market continues to slowly die. Amazingly, as the all-ceramic market has continued to expand, the indirect composite market is down 45 percent since 2003! In my communications with dentists as I lecture around the country, the reasons for the decrease in composites become clear. Dentists complain that the dismal insurance reimbursements for these restorations and their short clinical longevity (when compared to other restorations) are the main reasons they have stopped placing composite inlays and onlays.

Th 0611demet02
Fig. 2 - Even though the patient decided not to treat the entire arch, the zirconia crowns on teeth #7-10 have a significant esthetic improvement in his smile. Because of the zirconia coping, there is no possibility of a gray margin ever appearing.
Click here to enlarge image

It is easy to profit from metal-free restorations because, by definition, they are appearance-related and typically esthetic in nature. Since they often are used to improve a patient’s smile, many patients are more motivated to have this type of treatment done as compared to ordinary restorative treatment. Furthermore, for restorations such as porcelain veneers, there is no insurance benefit paid. This allows practitioners to set fees at any level they feel is fair. For example, I think that preparing and bonding veneers is more difficult than preparing and cementing crowns. Therefore, I believe that veneers should have a higher fee than typical crowns. Many dentists I’ve met do charge 10 to 25 percent more per unit for their veneers. Again, since insurance doesn’t cover these restorations, you are free to set fees wherever you would like.

Th 0611demet03
Fig. 3 - This close-up photograph of the zirconia crowns on a black background highlights the natural incisal edge translucency of these restorations. The beauty of all-ceramics and the strength of a PFM is a winning combination.
Click here to enlarge image

Pressed ceramics, such as IPS Empress, were the first metal-free restoration to make a large impact on dentistry. The increase in popularity of porcelain veneers through the years can be tied directly to the development of pressed ceramics. I still think there is no restoration that is more esthetic than an Empress veneer. I find Empress veneers look better than even Empress crowns! When done by a skilled technician, these veneers can rival the beauty of a natural tooth. I still use a lot of pressed ceramics, but only for prep and no-prep veneers. Now that we have stronger cementable all-ceramics for use on bicuspid and molar crowns, I confine my pressed ceramic use to veneers. With the choices available in cementable all-ceramic crowns, I see no reason to ever do another pressed-ceramic crown, because of their lower strengths and the need to bond them into place.

Th 0611demet04
Fig. 4 - This portrait shot one week after the cementation of the clinical zirconia restorations shows the natural appearance of these high-strength restorations.
Click here to enlarge image

Explosive growth of zirconia
The biggest change in the all-ceramic market from 2005 has been the explosive growth of zirconia-based restorations. From 2005 to 2006, the zirconia-based crowns and bridges prescribed by dentists went up 417 percent. That is not a typo; it reads four hundred seventeen percent! The two biggest products in that category are LAVA and Clinical Zirconia, although Cercon and Procera are in that category as well. Why does zirconia seem to be catching on so fast? Much of it stems from repeat business from dentists who are satisfied with the products. Let’s take a closer look at zirconia and how it came to be used in dentistry.

Th 0611demet05
Fig. 5 - Clinical case two consists of zirconia crowns on teeth #8 and 9. Because of the dark shade of these endodontically treated teeth, it is not possible to use a pressed all-ceramic crown. Zirconia copings will keep the prep from showing through, regardless of how dark they are.
Click here to enlarge image

The search for a high-strength, esthetic, biocompatible metal-free material that could be used for multi-unit frameworks as well as single-unit restorations has been the focus of many research and development efforts during the last decade. Some dentists have wanted these materials in order to avoid the use of metals in the mouth because of their potential allergenicity, while others have just wanted to provide the most esthetic restoration possible. Several materials have been developed in an attempt to meet these needs, yet have fallen short of clinician expectations because of low strength and toughness. Many clinical studies have shown that the fracture toughness and flexural strength of zirconia are significantly higher than that of alumina or any other esthetic ceramic on the market today.

Th 0611demet06
Fig. 6 - A digital X-ray of the zirconia crowns at try-in shows how dense the underlying zirconia copings are - they almost appear to be metal. The X-ray also is used to verify the fit of the zirconia crowns prior to cementation.
Click here to enlarge image

Zirconia (zirconium oxide, ZrO2) is a highly stable ceramic oxide typically used in industrial applications requiring high strength and stability, and zirconia has a history as a biomaterial dating back to the 1970s. It is used in implants and other nondental applications, and is one of the materials used in total hip replacements. Hip replacements parallel dental applications in that they are both load-bearing situations with proximity to vascular and osseous tissue. They both are applications that experience wear.

Th 0611demet07
Fig. 7 - With the zirconia crowns backlit, the translucency of the crowns is apparent even though the copings are dense enough to block out the prep shades.
Click here to enlarge image

Zirconia is unique among dental ceramics in that it exhibits a physical property called transformational toughening (strengthening). Through the use of additives, such as yttrium oxide, zirconia can be made in the tetragonal crystal structure at room temperature. When an external energy source, such as the stress at the tip of a crack, is applied to the material, it goes through an instantaneous phase transformation to a monoclinic crystal structure. This monoclinic form of zirconia crystal is about 4 percent larger in volume than the tetragonal form. At the microscopic tip of the crack, this expansion upon transformation acts to clamp the crack shut, thus resisting crack propagation. This process of actively resisting crack growth is very important in fatigue situations, such as those caused by chewing forces on a restoration. Because of this strength, anterior crown copings can be manufactured as thin as 0.3 millimeters. At this dimension, the copings have a beautiful, pearlescent translucency that allows natural light to reach the preparation, much like a natural tooth.

Th 0611demet08
Fig. 8 - The zirconia crowns blend in well with surrounding dentition, and there is no fear that one day gray margins will appear at the margins if any gingival recession happens to occur.
Click here to enlarge image

Zirconia is indicated for the fabrication of anterior and posterior single-unit crowns, and three-unit bridges in the anterior and posterior. Zirconia is not currently indicated for long-span bridges, cantilever bridges, or Maryland bridges; a PFM bridge is still indicated in these situations.

Th 0611demet09
Fig. 9 - Clinical case three consists of a full upper arch of zirconia restorations. In addition to the other esthetic challenges that are present, notice the shades of teeth #9 and 10, which have been endodontically treated.
Click here to enlarge image

The zirconia preparation is accomplished in accordance with the general principles common to most all-ceramic systems. Standard all-ceramic-modified shoulder margins (accomplished with burs containing the KR designation) or chamfer margins 1 mm deep are both acceptable. Proximal reduction of 1.5 mm is ideal, as is 1.5 mm to 2.0 mm of occlusal reduction. The taper of the final preparation should be 6 to 8 degrees and undercuts are not desirable, although these can be addressed in the laboratory if necessary

Th 0611demet10
Fig. 10 - The prep shade of the teeth is within normal limits with the exception of teeth #9 and 10. The discoloration of these teeth presents a difficult esthetic challenge for all-ceramic restorations. While I might prefer to use an esthetic PFM such as Captek, the patient insisted on all-ceramic crowns.
Click here to enlarge image

null

Th 0611demet11
Fig. 11 - This lateral view of the finished restorations looks directly at the discolored teeth, which have been completely blocked out by the zirconia crowns. With all-ceramic restorations, it can be a challenge to get restorations to blend in a case such as this.
Click here to enlarge image

Dr. Michael DiTolla is the Director of Clinical Research and Education at Glidewell Laboratories in Newport Beach, Calif. He lectures on both restorative and cosmetic dentistry. Dr. DiTolla has several clinical programs available on DVD through Glidewell. For more information on this article, or for more information on receiving a free copy of one of Dr. DiTolla’s clinical DVDs, e-mail him at mcditolla@mac.com, or call (888) 535-1289.
